• Touch screen controller of each working step
  • Washout and pre-dryer section
  • Washout of the plate via two orbital brushes
  • Sponge roller that grants the removal of the water excess before the pre-dryer
  • Cleaning through a cylindrical brush
  • Process water separated from the cleaning water
  • Detergent doser pump


  • Exposure section, dryer, anti-tack and post-exposure
  • Sand filter recycling unit (40 Liters capacity)
  560 760 920 107
Max plate size (mm) 520x760 760x1100 920x1200 1070x1530
Max plate size (inches) 20''x29'' 29''x43'' 36''x47'' 42''x60''
Tank capacity (l) 45 80 110 110
Wattage (kW) 7,5 13 13 13
Electrical supply 230V (3PH+GND) 60Hz
400V (3PH+N+GND) 50Hz
Overall size (LxWxH) cm 128x331x110 149x331x110 163x331x110 323x331x110
Weight (kgs) 400 600 700 950
